SPECIFICATION
Module Input：20W
Laser Output Power：CW 5.5W , Pulse 7.5W
Wavelength： 445-450nm
Beam Shape：0.08×0.08mm Focus Dot (Focusable)
Input Voltage： DC 12V
TTL&PWM Modulation： YES, Compatible with Both TTL & PWM Modulation
Input Voltage： DC12V
PWM/TTL Input： DC3.3V-12V
Input Interface： PH2.0-4Pin (+,-, PWM/TTL, Temperature), 3Pin (+,-, PWM/TTL) , 2Pin+2Pin (+,-) + (PWM/TTL,-)
Drive Mode：External ACC
Safe temperature range：<60 ℃
Module weight：204g
Life Time：20,000 hours
Package Included
- 1 x Laser Engraving Module
- 2 x Screw
- 2 x ABS cushion post
- 1 x L-shaped wrench
- 1 x 4 Pin Cable(300mm Sports Cable)
- 1 x NEJE Interface adapter board
- 1 x air asisst kits
